DeWalt DWS774 Original Instructions

27
• Check the technical data of the new blade: Use 216 mm saw blades with
30 mm arbor holes to obtain the desired cuttingcapacities.
• Replace the kerf plate when worn. If the kerf plate becomes worn or
damaged take saw to an authorised servicecentre.
Operating
General
• Use the optional roller tables for large and long pieces ofwood.
• Use the optional dustextraction.
• Never use your saw without the kerfplate.
Before use
• Check for damage to the tool and the power cable. Take care that
the power supply cord is not placed in the cutting area
• Check the upper blade guard, movable lower blade guard as well as
the dust extraction tube to determine that it will operateproperly.
• Check the lower blade guard , it is designed to close quickly when
the lever is released. If it does not close within 1 second, have the
saw serviced by an authorized
DeWALT
repairagent.
• Ensure that chips, dust or workpiece particle cannot lead to blockage
of one of thefunctions.
• In case of workpiece fragments jammed between saw blade and
guards disconnect the tool from the power supply. Remove the
jammed parts and reassembling the sawblade.
• Allow the blade to cut freely. Do notforce.
• Always make dry runs (without power) before finish cuts so that you
can check the path of theblade.
• Allow the motor to reach full speed beforecutting.
• Make sure all locking knobs and clamp handles aretight.
WARNING: Improper use can cause seriousharm.
• Be sure that the tool is in the “off” position before pluggingin.
• Do not let persons, especially children, not involved in the work,
touch the tool or the extension cord and keep them away from
the workarea.
Body and hand position
• Never place your hands closer than 100 mm from theblade.
• Never cross yourhands.
• As you move the saw arm left and right, follow it and stand
slightly to the side of the sawblade.
Cutting
• Always let the blade come to a full stop before raising the arm.
If small fibres of wood still split out at the rear of the workpiece,
stick a piece of masking tape on the wood where the cut will
be made. Saw through the tape and carefully remove tape
whenfinished.
• Hold the workpiece tightly to the table and the fence when
cutting. Keep your hands in position until the switch has been
released and the blade has completelystopped.
• When mitring the end of a piece of wood with a small off-cut,
position the wood to ensure that the off-cut is to the side of the
blade with the greater angle to the fence, i.e:
- left mitre, off-cut to the right
- right mitre, off-cut to the left
After use
• Disconnect the power cable from the powersupply.
• Store the Mitre Saw in a dry place and locked up securely, out of
reach ofchildren.
Dust Extraction
WARNING: Risk of dust inhalation. To reduce the risk of personal
injury ALWAYS wear approved dustmask.
WARNING: ALWAYS use a vacuum extractor designed in
complaince with the applicable directives regarding dust emission
when sawingwood.
• Certain dusts, such as oak or beech dust, are considered
ascarcinogenic.
• Observe the relevant regulations in your country for the materials to
beworked.
NOTICE:
• Connect the saw to a dust collection device when sawing wood. Always
consider factors which influence exposure of dust such as:
- good ventilation of the working place;
- sharpness of the saw blade;
- correct adjustment of the saw blade,
- Push the saw through the workpiece. Do not pull the saw through
theworkpiece.
Cleaning and Maintenance
The mitre saw has been designed to operate over a long period of time
with a minimum of maintenance. Continuous satisfactory operation
depends upon proper tool care and regularcleaning.
WARNING: Electrical shock can cause serious injuries ordeath.
• Before cleaning: Disconnect the power cable from the powersupply.
NOTICE:
• Use a cloth dampened only with water and mildsoap.
• Never let any liquid get inside the tool; never immerse any part of the
tool into aliquid.
• The guide grooves can become clogged with sawdust. Use suitable dust
extraction or some low pressure air to clear the guidegrooves.
• Disconnect the machine from the mains before carrying out any
maintenance work or when changing theblade.
• Never perform any cleaning or maintenance work when the machine is
still running and the head is not in the restposition.
Disposal
Protecting the environment!
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is
available at www.2helpU.com.

DeWalt DWS774 Specifications

General

Input power	1400 W
Output power	1100 W
Power source	AC
Blade bore	30 mm
Blade diameter	216 mm
Idle speed (max)	4500 RPM
Sound power level	104 dB
Cutting depth (90º)	70 mm
Sound pressure level	93 dB
Sound level uncertainty	3 dB
Cross cut capacity (0° x 0°)	250 x 62 mm
Bevel cut capacity (0° x 45°)	173 x 62 mm
Miter cut capacity (45° x 0°)	177 x 62 mm
Compound cut capacity (45° x 45°)	190 x 48 mm
Saw blade included	Yes
Diamond disc	-
Uncertainty K	1.5 m/s²
Vibration emission	2.1 m/s²

Weight and Dimensions

Depth	550 mm
Width	490 mm
Height	590 mm
Weight	12000 g
