8
ENGLISH
English (original instructions)
MITRE SAW
DWS779, DWS780
Congratulations!
You have chosen a D
tool. Years of experience, thorough product
development and innovation make
one of the most reliable
partners for professional power tool users.
Technical Data
DWS779 DWS780
Voltage
V
AC
230 230
UK & Ireland
V
AC
115 115
Type
10 11
Power input
W 1675 1675
Blade diameter
mm 305 305
Blade bore
mm 30 30
Blade body thickness
mm 1.8 1.8
Max. blade speed
min
-1
4100 1900–3800
U.K. & Ireland
min
-1
3900 1600–3600
Max. cross-cut capacity 90°
mm 349 349
Max. mitre capacity 45°
mm 244 244
Max. depth of cut 90°
mm 112 112
Max. depth of bevel cross-cut 45°
mm 56 56
Mitre (max. positions)
left 50° 50°
right 60° 60°
Bevel (max. positions)
left 49° 49°
right 49° 49°
0° mitre
Resulting width at max. height 112 mm
mm 299 299
Resulting width at max. height 110 mm
mm 303 303
Resulting height at max. width 345 mm
mm 76 76
45° mitre left
Resulting width at max. height 112 mm
mm 200 200
Resulting height at max. width 244 mm
mm 76 76
45° mitre right
Resulting width at max. height 112 mm
mm 211 211
Resulting height at max. width 244 mm
mm 76 76
45° bevel left
Resulting width at max. height 63 mm
mm 268 268
Resulting height at max. width 345 mm
mm 44 44
45° bevel right
Resulting width at max. height 62 mm
mm 193 193
Resulting height at max. width 345 mm
mm 28 28
Automatic blade brake time
s < 10 < 10
Weight
kg 25.4 25.4
Noise values and vibration values (triax vector sum) according to EN61029
L
PA
(emission sound pressure level) dB(A) 93 93
L
WA
(sound power level) dB(A) 100 100
K (uncertainty for the given sound level) dB(A) 3.0 3.0
Vibration emission value a
h
=
m/s
2
< 2.5 < 2.5
Uncertainty K =
m/s
2
1.5 1.5
The vibration emission level given in this information sheet has been
measured in accordance with a standardised test given in EN61029 and
may be used to compare one tool with another. It may be used for a
preliminary assessment of exposure.
WARNING: The declared vibration emission level represents the
main applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the
vibration emission may differ. This may significantly increase the
exposure level over the total working period.
An estimation of the level of exposure to vibration should also take
into account the times when the tool is switched off or when it is
running but not actually doing the job. This may significantly reduce
the exposure level over the total working period.
Identify additional safety measures to protect the operator from the
effects of vibration such as: maintain the tool and the accessories, keep
the hands warm, organisation of work patterns.
Fuses:
Europe 230V tools 10 Amperes, mains
U.K. & Ireland 230V tools 13 Amperes, in plugs
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word.
Please read the manual and pay attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury which,
if not avoided, may result in property damage.
Denotes risk of electric shock.
Denotes risk of fire.
EC-Declaration of Conformity
Machinery Directive
Mitre saw
DWS779, DWS780
declares that these products described under Technical Data are
in compliance with:
2006/42/EC, EN61029-1:2009 +A11:2010, EN61029-2-9:2012 +A11:2013
These products also comply with Directive 2014/30/EU and 2011/65/EU. For
more information, please contact
at the following address or refer
to the back of the manual.
The undersigned is responsible for compilation of the technical file and
makes this declaration on behalf of
.
Markus Rompel
Director Engineering
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
20.04.2016
