DeWalt XR DCB094K User Manual

16
ENGLISH
USB Charging Ports (Fig. A)
The DeWALT USB charger
3
is equipped with a USB Type‑A port
4
and a bi‑directional USB
Type‑C Port
5
.
Type-C port supports: Source – Power Delivery 3.0, Qualcomm
***
QC3.0/2.0, Samsung™
AFC, BC 1.2, Type C only
‑ Sink – BC 1.2, Apple
****
charging, PD 3.0, Type C only
‑ USB Type C can sink or source up to 100W
Type-A port supports: BC1.2 and Apple FastCharge and Samsung™FastCharge (AFC).
Output only. USB Type‑A port capable of12W.
Installing and Removing the Battery Pack (Fig. B)
NOTE: For best results, make sure your battery pack is fullycharged.
IMPORTANT: To avoid battery charge depletion, remove the battery pack from the
DeWALT USB charger when not inuse.
Over‑Discharge Protection
Over‑discharge protection will completely shut down the USB charger and require the
user to remove the battery pack for at least 5seconds and re‑insert into the DeWALT USB
charger to useagain. The user should ensure they see the power‑up blink pattern upon
insertion to ensure properoperation.
To Install Battery Pack
Slide the battery pack
1
into the DeWALT USB charger
3
until the battery pack is
firmlyseated.

WARNING: Fire hazard. Do not store or carry the battery pack so that metal
objects can contact exposed batteryterminals.
To Remove the Battery Pack
Press the battery release button
2
and pull the USB charger from thebattery.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and applicableregulations.

WARNING: To reduce the risk of serious personal injury, turn tool off and
disconnect battery pack before making any adjustments or removing/
installing attachments or accessories. An accidental start‑up can causeinjury.

DeWalt XR DCB094K Specifications

General

Brand	DeWalt
Model	XR DCB094K
Category	Battery Charger
Language	English
