OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Speed Selection (Fig.A, E)
The tool features two speed settings for greaterversatility.
NOTE: Do not change speeds when the tool is running.
Always allow the tool to come to a complete stop before
changingspeed.
1. To select speed 1(high torque setting), turn the tool off
and permit it to stop. Slide the speed selector
7
forward
(towards thechuck).
2. To select speed 2(high speed setting), turn the tool off and
permit it to stop. Slide the speed selector back (away from
thechuck).
3. If the tool does not change speeds, confirm that the speed
selection switch is completely engaged in the forward or
backposition.
Mode Selection (Fig.A, D)
The mode selection collar
6
can be used to select the correct
operating mode depending upon the plannedapplication.
To select, rotate the collar until the desired symbol aligns with
thearrow.

WARNING: When the mode selection collar is in the drill
or hammerdrill positions, the drill will not clutch. The drill
may stall if overloaded, causing a suddentwist.
DCD100, DCD100Y
Symbol Mode
Drilling
1-15 Screwdriving (higher number = greater torque)
Hammerdrilling
Proper Hand Position (Fig.F)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a suddenreaction.
Proper hand position requires one hand on the main handle
3
and the other hand holding the battery pack
1
.
Installing a Bit or Accessory into a Keyless
Chuck (Fig.C)

WARNING: Do not attempt to tighten drill bits (or
any other accessory) by gripping the front part of the
chuck and turning the tool on. Damage to the chuck
and personal injury may result. Always lock off trigger
switch and disconnect tool from power source when
changingacces sories.

WARNING: Always ensure the bit is secure before starting
the tool. A loose bit may eject from tool causing possible
personalinjury.
To insert a drill bit
13
or other accessory, follow thesesteps.
1. Turn tool off and remove batterypack.
2. Grasp the black sleeve of the chuck with one hand
and use the other hand to secure the tool. Rotate the
sleeve counterclockwise far enough to accept the
desiredaccessory.
3. Insert the accessory about 19 mm into the chuck
9
and
tighten securely by grasping and rotating the chuck sleeve
10
clockwise with one hand while holding the tool with the other.
When the chuck is nearly tightened you will hear a clicking
sound. Tighten the sleeve until the clicks stop and it will not
rotate any further. Your tool is equipped with an automatic
spindle lock mechanism. This allows you to open and close the
chuck with onehand.
4. Be sure to tighten chuck with one hand on the chuck sleeve
and one hand holding the tool for maximumtightness.
5. To release the accessory, repeat steps 1and 2above.
Variable Speed Trigger and Forward/Reverse
Control Button (Fig.A)
The tool is turned on and off by pulling and releasing the
variable speed trigger switch
4
. The farther the trigger is
depressed, the higher the speed of the tool. Your tool is
equipped with a brake. The chuck will stop as soon as the
trigger switch is fullyreleased.
A forward/reverse control button
5
determines the rotational
direction of the tool and also serves as a lock-offbutton.
• To select forward rotation (clockwise), release the trigger
and depress the forward/reverse control button on the right
side of thetool.
• To select reverse (counterclockwise), depress the forward/
reverse control button on the left side of thetool.
NOTE: The centre position of the control button locks the tool
in the off position. When changing the position of the control
button, be sure the trigger isreleased.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
beavoided.
NOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start-up. This is normal and
does not indicate aproblem.
Worklight (Fig.A)
The worklight
8
is activated when the trigger switch
4
is
depressed, and will automatically turn off 20seconds after
the trigger switch is released. If the trigger switch remains
depressed, the worklight will remainon.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as aflashlight.
