DeWalt XR DCD701 User Manual

DANSK
3
a
ADVARSEL: For at reducere risikoen for personskade bør
du læsebetjeningsvejledningen.
Definitioner: Sikkerhedsråd
Nedenstående definitioner beskriver sikkerhedsniveauet
for hvert signalord. Læs vejledningen og læg mærke til
dissesymboler.

FARE: Angiver en overhængende farlig situation, der
- hvis den ikke undgås - vil resultere i dødsfald eller
alvorligpersonskade.
EF-Konformitetserklæring
Maskindirektiv
Bor/driver/Slagboremaskine
DCD701, DCD706
DeWALT erklærer, at produkterne beskrevet under Tekniske data
er udformet i overensstemmelse med:
2006/42/EF, EN62841-1:2015+AC:2015, EN62841-2-
1:2018+A11:2019.
Disse produkter overholder også direktivet 2014/30/EU og
2011/65/EU. Kontakt
DeWALT på følgende adresse for yderligere
oplysninger eller se bagsiden afmanualen.
Undertegnede er ansvarlig for kompilering af den tekniske fil og
udsteder denne erklæring på vegne af
DeWALT.
Markus Rompel
Direktør for maskinteknik
DeWALT, Richard-Klinger-Strase 11,
65510, Idstein, Tyskland
20.09.2021

ADVARSEL: Det angivne vibrations- og/eller
støjemissionsniveau repræsenterer værktøjets
hovedanvendelsesområder. Hvis værktøjet anvendes til
andre formål, med andet tilbehør eller vedligeholdes
dårligt, kan vibrations- og/eller støjemissionen imidlertid
variere. Det kan markant forøge eksponeringsniveauet
over den samledearbejdsperiode.
Et estimat af eksponeringsniveauet for vibration og/eller
støj bør også tage højde for de gange, hvor der slukkes for
værktøjet, eller når det kører, men ikke bruges til arbejde.
Det kan markant mindske eksponeringsniveauet over den
samledearbejdsperiode.
Identificer yderligere sikkerhedsforanstaltninger for at
beskytte operatøren mod virkningerne af vibrationer og/
eller støj, såsom: Vedligehold værktøjet og tilbehør, hold
hænderne varme (relevante for vibrationer), organisering
afarbejdsmønstre.
Vibrations- og/eller støjemissionsniveauet, der er angivet i
dette vejledningsark, er målt i overensstemmelse med en
standardiseret test, der er angivet i EN62841 og kan anvendes til
at sammenligne et værktøj med et andet. Det kan anvendes til en
foreløbigeksponeringsvurdering.
DCD701 DCD706
Spænding
Spids
V
DC
12 12
Nominel V
DC
10,8 10,8
Type
2 2
Batteritype
Li-Ion Li-Ion
Udgangsspænding
W 250 250
Hastighed ved ingen belastning
1. gear
min
-1
0–425 0–425
2. gear
min
-1
0–1500 0–1500
Slag pr. minut
1. gear
- 0–7225
2. gear
- 0–25500
Maks. drejemoment (hård/blød)
Nm 57,5/25,5 57,5/25,5
Patronkapacitet
mm 10 10
Maksimum borekapacitet:
Træ
Metal
Murværk
mm
mm
mm
20
10
-
20
10
10
Vægt (uden batteripakke)
kg 0,87 0,96
Støjværdier og/eller vibrationsværdier (triax vector sum) i henhold til
EN62841-2-1:
L
PA
(emissionslydtryksniveau) dB(A) 72 83
L
WA
(lydeffektniveau) dB(A) 83 94
K (usikkerhed for det angivne
lydniveau)
dB(A) 3 3
Boring i metal
Vibrationsemissionsværdi a
h,D
= m/s
2
2,5 3,1
Usikkerhed K = m/s
2
1,5 1,5
Boring i beton
Vibrationsemissionsværdi a
h,ID
= m/s
2
- 15,5
Usikkerhed K = m/s
2
- 4
Skruning
Vibrationsemissionsværdi a
h
= m/s
2
2,5 <2,5
Usikkerhed K = m/s
2
1,5 1,5
Tillykke!
Du har valgt et DeWALT-værktøj. Mange års erfaring, ihærdig
produktudvikling og innovation gør DeWALT én af de mest
pålidelige partnere for professionelle brugere afelværktøj.
Tekniske Data
Dansk (oversat fra original brugsvejledning)
SUBKOMPAKT BORE-/SKRUEMASKINE/HAMMERBOR
DCD701, DCD706
