DeWalt XR DCD716 User Manual

12
ENGLISH
Protecting the Environment
w
Separate collection. Products and batteries marked
with this symbol must not be disposed of with
normal householdwaste.
Products and batteries contain materials that
Optional Accessories

WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
D
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
C
Lubrication
Your power tool requires no additionallubrication.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
The charger and battery pack are notserviceable.
will cause slower drilling speeds, overheating and lower
drillingrate.
4. Drill straight, keeping the bit at a right angle to the work. Do
not exert side pressure on the bit when drillling as this will
cause clogging of the bit flutes and a slower drillingspeed.
5. When drilling deep holes, if the hammer speed starts to
drop off, pull the bit partially out of the hole with tool stil
running to help clear debris from thehole.
NOTE: A smooth, even flow of dust from the hole indicates
proper drillingrate.
Hammerdrill Operation (Fig.D)
1. Turn the collar
3
to the hammerdrillsymbol.
2. Select the high speed setting by sliding the selector back
(away from thechuck).
IMPORTANT: Use carbide-tipped or masonry bitsonly.
3. Drill with just enough force on the hammer to keep it from
bouncing excessively or “rising” off the bit. Too much force
Drill Operation (Fig.C)

WARNING: TO REDUCE THE RISK OF PERSONAL
INJURY, ALWAYS ensure workpiece is anchored or
clamped firmly. If drilling thin material, use a wood
“back‑up” block to prevent damage to thematerial.
1. Turn the collar
3
to the drillsymbol.
2. Select the desired speed/torque range using the
gear shifter
4
to match the speed and torque to the
plannedoperation.
3. For WOOD, use twist bits, spade bits, power auger bits or
hole saws. For METAL, use high-speed steel twist drill bits
or hole saws. Use a cutting lubricant when drilling metals.
The exceptions are cast iron and brass which should be
drilleddry.
4. Always apply pressure in a straight line with the bit. Use
enough pressure to keep drill biting, but do not push hard
enough to stall the motor or deflect thebit.
5. Hold tool firmly with both hands to control the twisting
action of the drill. If model is not equipped with side handle,
grip drill with one hand on the handle and one hand on the
batterypack.

CAUTION: Drill may stall if overloaded causing a sudden
twist. Always expect the stall. Grip the drill firmly to control
the twisting action and avoidinjury.
6. IF DRILL STALLS, it is usually because it is being
overloaded or improperly used. RELEASE TRIGGER
IMMEDIATELY, remove drill bit from work, and determine
cause of stalling. DO NOT CLICK TRIGGER ON AND OFF
IN AN ATTEMPT TO START A STALLED DRILL  THIS
CAN DAMAGE THEDRILL.
7. To minimize stalling or breaking through the material,
reduce pressure on drill and ease the bit through the last
fractional part of thehole.
8. Keep the motor running when pulling the bit back out of a
drilled hole. This will help preventjamming.
9. With variable speed drills there is no need to centre punch
the point to be drilled. Use a slow speed to start the hole
and accelerate by squeezing the trigger harder when the
hole is deep enough to drill without the bit skippingout.
MAXIMUM RECOMMENDED CAPACITIES
Low Range–1 High Range–2
Bits, Metal Drilling 6.35 mm 3.18 mm
Wood, Flat Boring 19.05 mm 12.7 mm
Hole Saws 19.05 mm 15.88 mm
