16
ENGLISH
Storage (Fig.C, E, S)
• Store in a dry, covered location above freezing temperature
with the batteries removed. STOREINDOORS.
• Always completetely empty water from high pressure hose,
pressure washer unit, nozzles, and spray wand.
• Nozzles can be stored in the nozzle storage slots in the
storage compartment
41
as shown in Fig.E and Fig. S.
• High pressure hose and suction hose can be stored coiled
up and secured between the cage and the pressure washer
unit
8
as shown in Fig.C.
• Spray wand can be stored, broken down into three pieces, in
the storage compartment
41
as shown in Fig.E and Fig. S.
• High pressure foamcannon
26
can be stored empty, in
the built in storage space in the pressure washer unit as
shown in Fig. C.
Cleaning
WARNING: Electrical shock and mechanical hazard.
Disconnect the electrical appliance from the power source
beforecleaning.
WARNING: To ensure safe and efficient operation,
always keep the electrical appliance and the ventilation
slotsclean.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Ventilation slots can be cleaned using a dry, soft non-metallic
brush and/or a suitable vacuum cleaner. Do not use water or
any cleaning solutions. Wear approved eye protection and an
approved dustmask.
Lubrication
Your power tool requires no additionallubrication.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Nozzle Cleaning (Fig.A, Q)
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
If the nozzle becomes clogged with foreign materials, such as dirt,
excessive pressure may develop. If the nozzle becomes partially
clogged or restricted, the pump pressure will pulsate. Clean the
nozzle immediately using the nozzlecleaner.
1. Turn OFF the pressure washer unit
8
by toggling the speed
selector switch
9
to the center position.
2. Turn off the watersupply
and
remove the battery packs from
the pressure washer unit
8
.
3. Pull trigger
7
on spray handle
4
to relieve any
waterpressure.
4. Remove the nozzle from the spray wand
2
by depressing
the nozzle button
3
on the spray wand and pulling
thenozzle.
5. Using the nozzle cleaning tool
27
, unclog any debris from
thenozzle.
6. Run water from a faucet or garden hose through thenozzle.
Suction Hose (Fig.K)
1. To clean the suction hose
28
, shut off the pressurewasher.
2. Pull the trigger switch to relieve any waterpressure.
3. Remove the suction hose
28
from the pressurewasher.
- Spraying head on tends to cause dirt particles to imbed
in thesurface.
- When working on vertical surfaces, it is best to apply
detergent starting at the bottom and working upwards
which will prevent the detergent from sliding down and
causingstreaks.
3. To disengage the spray handle, release thetrigger.
Moving the Pressure Washer (Fig.A–D)
1. Turn OFF the pressure washer unit
8
toggle the speed
selector switch
9
to the center position. Then turn off the
watersupply.
2. Point the spray wand
2
in a safe direction and pull the
trigger
7
to release remaining waterpressure.
3. When the spray wand is completely empty, pull up the
telescoping handle
12
and pull the pressure washer unit
using the wheels
15
to your nextlocation.
Shutdown (Fig.A, H, I, N, P)
1. Turn OFF the pressure washer unit
8
by toggling the speed
selector switch
9
to the center position. Then turn off
the watersupply
and
remove the battery packs from the
pressure washer unit
8
.
2. Discharge residual pressure by squeezing the trigger
7
until
no more water comes out of the spray wand
2
.
3. Engage the spray trigger lock-off
6
.
4. Disconnect the garden hose from the water intake
17
.
5. Disconnect the high pressure hose
1
from the high
pressure water outlet
18
and drainhose.
4. To clean the suction hose, use water from a garden hose to
thoroughly rinse out the suction hose and allow it to fullydry.
Suction Hose Filter (Fig.R)
1. Turn the filter
30
on the end of the suction hose
28
counterclockwise and remove.
2. Remove the strainer from inside of the filter.
3. Rinse all of the parts with clean water andreassemble.
