DeWalt XR DCS356 User Manual

14
ENGLISH
Proper hand position requires the tool to be held as shown in
FigureN.
Instructions for Use (Fig.N)
1. Install the batterypack.
2. To turn the tool ON, hold it as shown in FigureN and press
the variable speed trigger
1
.
NOTE: The further the trigger switch is depressed the faster
the tool will operate. If in doubt about the proper speed
for your operation, test the performance at low speed and
gradually increase until a comfortable speed isfound.
3. To turn the tool OFF, release the variable speed trigger
1
.
Lock On/Off Button (Fig.O)
The tool can be locked off by fully depressing the lock on/off
button
4
shown in FigureO.
For more comfort in extended use applications, the lock
on/off button
4
can lock the trigger trigger
1
in the
depressedposition.
Proper Hand Position (Fig. N)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.

WARNING: Ensure switch is fully OFF before installing
thebattery.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
2. Adjust the length of the guide by pulling out or pushing
inward to achieve the desired length as shown in FigureL.
3. Secure the guide in place by turning the depth/cut
adjustment knob
14
clockwise. To release the guide turn
the depth/cut adjustment knobcounterclockwise.
NOTE: The guide arm can also be placed in the guard assembly
vertically in order to set the height off a cut. Refer to FigureM.
Attaching the Dust Extraction Adaptor (Fig.Q)
The Dust Extraction Adaptor allows you to connect the tool to
an external dust extractor, either using the AirLock™ system
(DWV9000‑XJ), or a standard 35mm dust extractorfitment.
1. Attach the dust extraction adaptor
17
by inserting the
tabs
13
in to the accessory side mount slots
5
.
NOTE: The dust extraction adaptor can be attached to either
side of thetool.
2. Insert screw
15
and washer
21
into the dust extraction
adaptor
17
and tighten with the supplied hex wrench
16
.
NOTE: The tool will automatically shut off after operating
for five minutes with the lock‑on button engaged. To restart
the tool, the user will have to release the trigger and repress
lock‑onbutton.
Speed Selector (Fig.A)
DCS356
Your tool is equipped with a speed selector
10
which allows
you to select one of the three speeds that limits the full speed.
Select the speed based on the application and control the speed
of the tool using the variable speed trigger switch
1
.
LED Worklight (Fig.P)
The LED worklight
2
will activate when the trigger is depressed.
It will automatically shut off following a short period of time
once the trigger isreleased.
Using the Dust Extraction Adaptor with the
Sanding Platen (Fig.R)
1. Attach the dust extraction adaptor
17
. Refer to Attaching
the Dust ExtractionAdaptor.
2. Attach the sanding platen
23
as described under
Installing/RemovingAccessories.
3. Attach sanding sheet as described under Installing/
Removing SandingSheets.
Using the Dust Extraction Adaptor with
Plunge Cutting Accessory (Fig.S)
1. Attach the dust extraction adaptor. Refer to Attaching the
Dust ExtractionAdaptor.
2. Push dust extraction arm
19
into the lower aperture of the
dust extraction adaptor
17
.
3. Attach plunge cutting blade as described under Installing/
RemovingAccessories.
4. Adjust the dust extraction arm
19
for bestresults.
Helpful Hints
• Always ensure the workpiece is firmly held or clamped to
prevent movement. Any movement of the material may
affect the quality of the cutting or sandingfinish.
• Do not start sanding without having the sandpaper
attached to sandingplaten.
• Use coarse grit paper to sand rough surfaces, medium grit
for smooth surfaces and fine grit for the finishing surfaces. If
necessary, first make a test run on scrapmaterial.
• Excessive force will reduce the working efficiency and cause
motor overload. Replacing the accessory regularly will
maintain optimum workingefficiency.
• Do not allow the sandpaper to wear away, it will damage
the sandingpad.
• If the tool overheats, especially when used at low speed,
set the speed to maximum and run it with no load for 2–3
minutes to cool the motor. Avoid prolonged usage at very
low speeds. Always keep the bladesharp.
