DeWalt XR Li-ion DWH161 User Manual

9
ENGLISH
Inserting and Removing the Battery Pack
from the Dust Extractor (Fig. B)
NOTE: Make sure your battery pack
1
is fullycharged.
To Install the Battery Pack into the Dust Extractor
1. Align the battery pack
1
with the rails inside the dust
extractor (Fig.B).
2. Slide the battery pack in until it is firmly seated in the dust
extractor and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button
2
and firmly pull the battery pack
out of the dustextractor.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. B)
Some
DeWALT
battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
15
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn the dust extractor off and disconnect
battery pack before making any adjustments or
removing/installing attachments or accessories. An
accidental start-up can causeinjury.

WARNING: Use only
DeWALT
battery packs andchargers.
DeWALT
Bluetooth® Tool Tag Ready (Fig.H)
Optional Accessory

WARNING: Read instruction manual for the
DeWALT
Bluetooth® ToolTag.

WARNING: Turn dust extractor off and disconnect battery
pack before installing the
DeWALT
Bluetooth® ToolTag.

WARNING: When installing or replacing the
DeWALT
Bluetooth® Tool Tag, use only the screws provided. Be sure
to securely tighten thescrews.
Your dust extractor comes with mounting holes
17
for
installing a
DeWALT
Bluetooth® Tool Tag (DCE041). Use only the
original fasteners included with the tool tag. You will need a T15
(Torx) bit tip to install the tag. The
DeWALT
Tool Tag is designed
for tracking and locating professional power tools, equipment,
and machines using the
DeWALT
Tool Connect™ app. For proper
installation of the
DeWALT
Tool Tag refer to the
DeWALT
Tool
Tagmanual.
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Battery pack
2
Battery release button
3
Dust collection box
4
Dust collection box release
buttons
5
Filter cleaning mechanism
6
Dust extractor hose
7
Three position switch
8
Wireless Tool Control™
pairing button
9
LED
10
Carry strap
11
Carry strap hooks
12
Crevice tool
Intended Use
Your DWH161 cordless dust extractor can be used for mobile
operation to take up dry, non-combustable dusts. Only for
indooruse.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
DO NOT pick up materials that present a risk of explosion,
glowing or burning materials, flammable materials, gases or
other hazardoussubstances.
NOTE: This appliance is suited for professional and commercial
use, e.g. in hotels, schools, hospitals, factories, shops, offices,
rental companies, and on constructionsites.
Date Code Position (Fig. F)
The date code
14
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2020 XX XX
Year of Manufacture
Markings on Dust Extractor
The following pictograms are shown on the dust extractor:
Read instruction manual beforeuse.
1 Li-Ion battery pack (C1, D1, L1, M1, P1, S1, T1, X1, Y1 models)
2 Li-Ion battery packs (C2, D2, L2, M2, P2, S2, T2, X2, Y2 models)
3 Li-Ion battery packs (C3, D3, L3, M3, P3, S3, T3, X3, Y3 models)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by
DeWALT
is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
• This machine is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience andknowledge.
• Children should be supervised to ensure that they do not
play with theappliance.

DeWalt XR Li-ion DWH161 Specifications

General

Brand	DeWalt
Model	XR Li-ion DWH161
Category	Vacuum Cleaner
Language	English
