DeWalt XR Li-ion DWH161 User Manual

10
ENGLISH
Proper Hand Position (Fig. D)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
If used as a stand alone dust extractor, proper hand position
requires one hand on theaccessory.
Using the Dust Extractor (Fig.A)
• Before using the universal dust extractor, ensure that the
filter is in place and filter box is securelyfitted.
• Do not use damaged filters. Replace any damaged
filtersimmediately.
• Please observe national applicable regulations/laws on how
to handle harmful types of dust in yourcountry.
1. Attach the appropriate accessory to the dust extractor
hose
6
.
2. Insert the battery pack
1
.
3. To turn dust extractor on, press the three position switch
7
to the On (I)position.
4. To use in Wireless Tool Control mode press the three position
swtich to the Wireless Tool Control ( ) position. Once
paired the trigger of the connected tool will control the
dustextractor.
NOTE: Refer to Pairing the Dust Extractor with a Tool
using Wireless Tool Control Mode to use the dust extractor
with a Wireless Tool Control equippedtool.
5. When finished, turn the dust extractor off by pressing the
three position switch to the Off(O) position or releasing the
trigger of the Wireless Tool Control equippedtool.
Pairing the Dust Extractor with a Tool using
Wireless Tool Control Mode (Fig. A, E)

CAUTION: When the dust extractor is being controlled by
a paired power tool it may start or stop withoutwarning.
To Pair with a
DeWALT
Remote or Wireless Tool
Control Tool
1. Press the three position switch
7
to the Wireless Tool
Control ( )position.
2. Press and hold the Wireless Tool Control pairing button
8
on the DWH161 and pull the trigger on the Wireless Tool
Control equipped tool or press the button on the remote at
the sametime.
3. The LED
9
will be steadily illuminated to indicate a
successfulpairing.
NOTE: Only one transmitter can be paired to the DWH161
at a time. If the unit is already paired the previous
transmitter will beoverridden.
To Unpair with a Wireless Tool Control Tool
• Press and hold the Wireless Tool Control pairing button
8
on the DWH161 and pull the trigger on the Wireless Tool
Control equipped tool or press the button on the remote at
the sametime.
• The LED
9
will flash slowly to indicate a
successfulunpairing.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn the dust extractor off and disconnect
battery pack before making any adjustments or
removing/installing attachments or accessories. An
accidental start-up can causeinjury.
Attaching the Carry Strap (Fig. C)
Your dust extraction system comes with a carry strap
10
that
can be connected to the carry strap hooks
11
in either manner
as shown in Fig.C.
Attaching the Crevice Tool (Fig. A)
• To attach the crevice tool
12
to the dust extractor hose
6
,
insert the end of the dust extractor hose into the open end
of the accessory with a twisting motion untiltight.
NOTE: The dust extraction hose is not compatible with
AirLock®connectors.
• To remove the crevice tool, hold the dust extraction hose
and pull the accessory off using a twistingmotion.
Installing the Belt Hook (Fig. H)

WARNING: To reduce the risk of serious personal
injury, turn the dust extractor off and disconnect
battery pack before making any adjustments or
removing/installing attachments or accessories. An
accidental start-up can causeinjury.

WARNING: To reduce the risk of serious personal
injury, ONLY use the tool’s belt hook to hang the dust
extractor from a work belt. DO NOT use the belt hook
for tethering or securing the dust extractor to a person
or object during use. DO NOT suspend dust extractor
overhead or suspend objects from the belthook.

WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook
issecure.
IMPORTANT: When attaching or replacing the belt hook
18
,
use only the screw
13
that is provided. Be sure to securely
tighten thescrew.
If the hook is not desired at all, it can be removed from the
dustextractor.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
