36
Section 5 - Appendix
Specifications
General Specifications
A/D/A Converter: 24-bit high performance audio
Sampling Frequency: 44.1 kHz
DSP Section: AudioDNA2™ DSP Processor
Simultaneous Effects: 9
Preset Memory: 50 User Presets (1-50) / 50 Factory Presets (51-00)
Drum Machine: 40 Patterns
Dimensions: 6.5" Length x 8.5" Width x 2" Height
Unit Weight: 1.52 lbs.
Analog Input Connections:
Guitar Input: 1/4" Unbalanced (TS)
Input Impedance: 500k Ohms
Analog Output Connections:
Left/Right Outputs: 1/4" Unbalanced
Left/Right Output Impedance: 500 Ohms per side
Maximum Output: +7.0 dBu
Headphones: 1/8" Stereo (TRS) – 17.4mW per channel @ 50 Ohms
