Page 16
Calibrating the Expression Pedal
In the unlikely event that the expression pedal does not respond properly or that the note does
not bend or return to the correct pitch, it may need to be re-calibrated. The following steps outline
the procedure for expression pedal re-calibration:
1. Disconnect the power from the Whammy pedal.
2. Press and hold the
WHAMMY Effect Footswitch while reconnecting the power. This
enables MIDI and Calibration Setup. One of the
WHAMMY Effect LEDs will begin to flash
indicating the currently selected MIDI channel.
3. Rock the
Expression Pedal fully forward (toe down) and then press the DROP TUNE
Footswitch. When you press the footswitch, the DROP TUNE Effect Status LED will first
light Red and then change to Green indicating Expression Pedal calibration is now enabled.
If the
DROP TUNE Effect Status LED stays Red, make sure the Expression Pedal is
rocked fully forward and press the
DROP TUNE Footswitch until the LED lights Green.
4. Rock the
Expression Pedal fully back (toe up) and fully forward (toe down) at least two
times. The
SHIFT UP LEDs will light back and forth (from 1 to OCT + DRY) as the pedal
is rocked indicating the pedal is calibrating.
5. When finished, press the
WHAMMY Effect Footswitch again to exit the MIDI and
Calibration set up and return to normal operation.
This completes the expression pedal calibration procedure.
