Ditch Witch 1820 User Manual

32 1820 - TRANSPORTATION
LOADING
32 1820 - TRANSPORTATION
LOADING
Unload Machine
1. Remove tiedowns from trencher.
2. Open fuel shut-off valve on gasoline engine.
3. Start machine.
4. Slowly engage pump control.
5. Move throttle (black) to 1/2 open.
6. Engage axle lock (blue).
7. Pull boom control (green) to raise boom halfway.
8. Use speed/direction control (orange) to slowly back trencher
off trailer or down ramps.
Unload Machine
1. Remove tiedowns from trencher.
2. Open fuel shut-off valve on gasoline engine.
3. Start machine.
4. Slowly engage pump control.
5. Move throttle (black) to 1/2 open.
6. Engage axle lock (blue).
7. Pull boom control (green) to raise boom halfway.
8. Use speed/direction control (orange) to slowly back trencher
off trailer or down ramps.

Ditch Witch 1820 Specifications

General

Engine Power	18 hp
Fuel Type	Diesel
Horsepower	18 hp
Transmission	Hydrostatic
Drive System	4-wheel drive
