4 Intended use
The intended use of the awning is to provide shade.
The awning is to be used whilst the vehicle is stationary only.
5 Technical description
No. in
fig. 2
Quantity Description
2 2 Hardware assemblies
3 1 Door Roller Kit
4 2 Bottom mounting bracket
5 1 Pull rod
6 1 set Fixing materials
– 1 Installation and Operating Manual
Hardware
878HT-WH
878HT-BK
(Tall – Black or white)
878HS-WH
878HS-BK
(Standard – Black or
white)
Height range 1892 mm – 2235 mm 1626 mm – 1930 mm
Main arm length 1854 mm 1549 mm
Adjustable arm length 1448 mm 1448 mm
Main rafter length 1676 mm 1372 mm
Secondary rafter length 826 mm 1130 mm
