Hobs and Combinations Using the device
27
You must use a rigid gas line for the connection.
Observe the following instructions for the connection:
• Observe the national requirements.
• Use only steel pipe ∅8 x 1 mm (welded, seamless steel or stainless steel)
• Fasten the gas line to the side or rear wall of the surrounding furniture parts so that
no loads are placed on the actuators.
• The entire gas line must be free of stress.
➤ Connect the pipes as shown (fig. e, page 13).
➤ Attach a sign above the device with the following text:
“WARNING!
When cooking, additional ventilation must be provided, for example, by open-
ing windows near the device.
The device must not be used as a space heater.”
➤ Open the gas supply.
!
➤ Check all connections for leaks with leak spray.
There are no leaks if no bubbles form.
6.4 Connecting the device to the power supply
(models with electronic ignition only)
➤ Connect the device as shown (fig. f, page 13).
➤ Add a 1 A fuse in the plus line near the battery.
7 Using the device
7.1 Igniting a burner
!
WARNING! Beware of injury!
Never check for leaks with an open flame or near sources of ignition.
WARNING! Beware of injury!
The complete ignition process must be visible from above and must not
be hidden by pots placed on the stove.
