Installation DM50C
12
6 Installation
6.1 Notes on mounting into furniture
You can mount the minibar in four ways into furniture. Choose your favoured
alternative according to the following figure (page 13).
Observe the following:
• The cut-out dimensions H x W x D are:
– DM50CD: 443 x 570 x 490 mm
– DM50CF: 443 x 570 x (488 + d) mm
d is the thickness of the hotel‘s own decor
• The clearance between the minibar‘s back and the furniture wall should be
10 mm or more.
• The ventilation openings for the chosen alternative have to be produced as
shown in following figure (page 13).
• Air passing through the inlet air duct must not be heated by any heat sources
(heaters, direct sunlight, gas ovens etc.).
I
NOTE
The minibar must be levelled carefully to ensure proper function.
