DM50NTE Installation
15
Main drawer
Mini drawer
6 Installation
6.1 Notes on mounting into furniture
You can mount the minibar in four ways into furniture. Choose your favoured
alternative according to fig. 6, page 5.
Observe the following:
• The cut-out dimensions H x W x D are:
– DM50NTE D: 438 x 570 x 504 mm
– DM50NTE F: 438 x 570 x (502 + d) mm
d is the thickness of the hotel‘s own decor
• The clearance between the minibar‘s back and the furniture wall should be
approx. 15 mm.
• The ventilation openings for the chosen alternative have to be produced as
shown in fig. 6, page 5.
• Air passing through the inlet air duct must not be heated by any heat sources
(heaters, direct sunlight, gas ovens etc.).
No in
fig. 4, page 3
Description
1 Wide divider
2 Separator
3 Small divider
4 Bottle finger
No in
fig. 5, page 4
Description
1 Rotatable divider
2 Miniature bottle holder
DM50NTE-IO-16s.book Seite 15 Dienstag, 28. Februar 2017 3:33 15
