SinePower Fitting the inverter
11
7.2 Mounting instructions
When selecting the installation location, observe the following instructions:
• The inverter can be mounted horizontally or vertically.
• The inverter must be installed in a place that is protected from moisture.
• The inverter may not be installed in the presence of flammable materials.
• The inverter may not be installed in a dusty environment.
• The place of installation must be well ventilated. A ventilation system must be
available for installations in small, enclosed spaces. The minimum clearance
around the inverter must be at least 5 cm (fig. 4).
• The air intake on the back or the air outlet on the front of the inverter must remain
clear.
• For ambient temperatures higher than 40 °C (such as in engine or heating
compartments, or direct sunlight), the inverter may shut down although the
connected load is below the rated load (derating).
• The device must be installed on a level and sufficiently sturdy surface.
A
7.3 Mounting the inverter
➤ Mount the inverter as shown (fig. 5).
7.4 Mounting the remote control
➤ Mount the remote control as shown (fig. 6).
➤ Remove the protective film.
NOTICE!
Before drilling any holes, make sure that no electrical cables or other
parts of the vehicle can be damaged by drilling, sawing and filing.
DSP600-2000--IO-16s.book Seite 11 Montag, 7. Mai 2018 1:39 13
