user’s manual
15
TEC 40D
GB
Max 1.5m
3m
Generator TEC 40D is equipped as standard with an electric pump for pumping fuel. The following should be done.
The fuel tank should be installed with the tank basis at a maximum depth of 1.5 meters below the lower edge of the
generator box. For safety reasons ensure not to mount the generator box top edge higher than the tank top edge.
2.3 Instructions for the installation of the tank
TANK MAXIMUM LOWER EDGE
TANK MAXIMUM TOP EDGE
Generator
Generator
Tank
Tank
2 Installation instructions
