Dräger Interlock 5000 / 7000 17
Adjustable parameters
9 Adjustable parameters
Some instrument parameters may be set differently by a Dräger
Interlock service centre due to legal regulations in different countries
or individually during installation.
The descriptions of these Instructions for Use are related to the
basic version.
Table of essential adjustable parameters:
Power consumption
Maximum <2.5 A
Stand-by <1 mA
Switch relay for the lead for the
starter relay
<16 A, continuous
<40 A, peak
Output relay
switchable de-energized 48 V
switchable energized 24 V
Ignition lead 5 V to 48 V
Waiting time to ready for
measurement
Interlock 5000 Interlock 7000
20°C 7s 2s
0°C 15s <5s
-25 °C <60 s <60 s
-45°C <115s 110s
Parameter Basic version
Operation
Display of test result Test passed /
Test failed
Breath test volume 1.0 litre
Limit value (initial test) 0.30 ‰ or 0.20 ‰
Restart period 30 minutes
Data storage
Data storage On
Service
Calibration interval 365 days
Possible to start engine after the end of
the service interval
Yes
Retests
Retests (whilst the vehicle is in use) No
