XI. BASIC TROUBLESHOOTING
The diagnostic flash codes for your scooter are designed to help you perform basic
troubleshooting quickly and easily. A diagnostic flash code can be displayed in one of
two ways:
 A light labeled “Diagnostic” on the control panel will flash
OR
 The battery indicator light farthest to the left on the battery gauge (red light)
will flash
Please refer to the diagram below for flash codes, description of problem, and
recommended actions.
Flash Code
Description
Recommended Action
1
Low Battery Voltage
Charge battery
2
Motor Disconnect
Disconnect & Reconnect front and rear section
3
Motor Wiring Trip
Check motor connections
4
Freewheel Trip
Place the scooter in “drive” mode
5
N/A
N/A
6
Charger Inhibit
Disconnect the charger
7
Throttle Trip
Place throttle in neutral position
8
Controller Trip
Check connections at controller
9
Brake Trip
Place the scooter in “drive” mode
10
High Battery Voltage
Check battery connections
Once the recommended action is taken, turn the scooter off and then back on again to
clear the flash code. If the problem was not corrected, or another problem exists the
controller may display another flash code.
ATTENTION – Your scooter may have a diagnostic light on the tiller that
will stay on constantly. The light will begin to flash when you have a
serviceable item.
