22
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
15. PARTS LIST (DFA-45T/70T/125T/170C Models Only)
KEY NO. DESCRIPTION
PART NO.
DFA-45T DFA-70T DFA-125T DFA-170C
1 Fuel Tank Assembly 2151-0007-00 2151-0007-00 2151-0008-00 2151-0009-00
1-1 Drain Plug - - 3234-0059-00 3234-0059-00
2 Fuel Gauge 282-1001-01 282-1001-01 282-1001-00 282-1001-00
3 Fuel Filter Assembly 287-4000-20 287-4000-20 287-4000-21 287-4000-21
4 Fuel Cap 282-2000-90 282-2000-90 282-2000-90 282-2000-90
5 Power Cord 140-9000-013 140-9000-013 140-9000-013 140-9000-013
6 Power Switch 110-9400-001 110-9400-001 110-9400-001 110-9400-001
7 Thermostat Control Knob 3231-0111-00 3231-0111-00 3231-0111-00 3231-0111-00
8 Lower Shell 3111-0209-00 3111-0209-00 3111-0210-00 3111-0211-00
9 Air Line 287-5100-55 287-5100-55 287-5100-53 287-5100-54
10 Temperature Limit Control 154-9000-008 154-9000-008 154-9000-007 154-9000-007
11 Combustion Chamber 2152-0064-00 2152-0042-00 2152-0045-00 2152-0048-00
12 Photocell Bracket 285-4104-91 285-4104-90 285-4104-90 285-4104-90
13 Fuel Line 287-5100-50 287-5100-50 287-5100-52 287-5100-52
14 Photocell Assembly SP-KFA1007 SP-KFA1007 SP-KFA1007 SP-KFA1007
15 Burner Head Assembly See below See below See below See below
15-1 Nozzle SP-KFA1026 SP-KFA1027 SP-KFA1003 SP-KFA1004
15-2 Nozzle Seal Washer 285-8109-90 285-8109-90 285-8109-90 285-8109-90
15-3 Nozzle Seal Spring 285-8110-00 285-8110-00 285-8110-00 285-8110-00
15-4 Burner Head 284-7112-00 3531-0015-00 284-7112-11 284-7112-10
15-5 Spark Plug SP-KFA1008 SP-KFA1008 SP-KFA1009 SP-KFA1009
15-6 Nipple 3541-0039-00 3541-0039-00 3541-0020-00 3541-0020-00
16 Motor and Pump Assembly See below See below See below See below
16-1 Motor 111-9000-985 111-9000-985 111-9000-984 111-9000-955
16-2 Pump Body 288-3100-00 288-3100-00 288-3100-00 288-3100-00
16-3 Rotor Kit SP-KFA1000 SP-KFA1000 SP-KFA1000 SP-KFA1000
16-4 Blade See SP-KFA1000 See SP-KFA1000 See SP-KFA1000 See SP-KFA1000
16-5 End Pump Cover 288-3100-10 288-3100-10 288-3100-10 288-3100-10
16-6 Filter Kit SP-KFA1005 SP-KFA1005 SP-KFA1005 SP-KFA1005
16-7 Lint Filter See SP-KFA1005 See SP-KFA1005 See SP-KFA1005 See SP-KFA1005
16-8 Output Filter See SP-KFA1005 See SP-KFA1005 See SP-KFA1005 See SP-KFA1005
16-9 End Filter Cover 288-3100-40 288-3100-40 288-3100-40 288-3100-40
16-10 Plug/Pump Adj. Kit SP-KFA1006 SP-KFA1006 SP-KFA1006 SP-KFA1006
16-11 Ball See SP-KFA1006 See SP-KFA1006 See SP-KFA1006 See SP-KFA1006
16-12 Spring See SP-KFA1006 See SP-KFA1006 See SP-KFA1006 See SP-KFA1006
16-13 Adj. Screw See SP-KFA1006 See SP-KFA1006 See SP-KFA1006 See SP-KFA1006
16-14 Capacitor 3820-0142-00 3820-0142-00 3820-0143-00 3820-0143-00
16-15 Nipple 3541-0020-00 3541-0020-00 3541-0020-00 3541-0020-00
To Next Page
