７
5. Connection and Operation
5.1 Connection and operation for 1000H(XL)/ 2000H(XL)/ 3000H(XL)
1) Inspection: Inspect the packaging carton and its contents for damage. Please inform the
transport agency immediately should you find signs of damage.
Please keep the packaging in a safe place for future use.
Note: Please ensure that the incoming feeder is isolated and secured to prevent it
from being switched back on again.
2) Connection:
2.1) UPS Input Connection
If the UPS is connected via the power cord, please use a proper socket with
protection against electric current, and pay attention to the capacity of the socket:
over 10A for 1000H(XL)/2000H, over 16A for 2000HXL/3000H(XL).
2.2) UPS Output Connection
The output of 1000H(XL) and 2000HXL (Non CE) are socket-types only. Simply
plug the load power cord to the output sockets to complete connection.
Model No.
Output Socket (pcs) Terminal Block
1000H(XL) 4 Nil
2000H 6 Nil
2000HXL 4(CE) 6(Non CE) Available(CE) Nil (Non CE)
3000H(XL) 4(CE) 3(Non CE) Available
Besides output sockets, 2000HXL (CE) and 3000H(XL) has the terminal block
available for output as well. The wiring configuration is shown as the following
procedure:
a) Remove the small cover of the terminal block
b) Use AWG14 or 2.1mm
2
wires for wiring configuration
c) Upon completion of the wiring configuration, please check whether the wires
are securely affixed.
d) Put the small cover back to the rear panel.
The system may be installed and wired only by qualified electricians in
accordance with applicable safety regulations!
When installing the electrical wiring, please note the nominal amperage of
your incoming feeder
To Next Page
