Eaton 2 Series User Manual

26
Parts List – Series 2 Kits
Item Part No. Qty. Description
12-6 95912-125 4 Cap Screw 5/16-18
12-7 108377-000 4 Washer
12-8 108340-000 4 Hold Down Strap
12-9 103237-002 4 Spacer
990724-000
Hold Down Kit – Models 54, 64
89,2 – 105,4 cm
3
/rev
990723-000
Hold Down Kit – Models 33, 39, 46
54,4 – 63,7 – 75,4 cm
3
/rev
Item Part No. Qty. Description
116 C 110192-000 1 Drive Shaft Seal
117 C 101680-250 1 Retaining Ring
118 C 107836-000 1 Spacer
990753-000
Shaft Seal Kit – Models 54, 64
89,2 – 105,4 cm
3
/rev
990709-000
Shaft Seal Kit – Models 33, 39, 46
54,4 – 63,7 – 75,4 cm
3
/rev
990713-000
Low Pressure Relief Valve Kit
990388-000
Shim Kit, End Cover Bearing
Models 54, 64 / 89,2 – 105,4 cm
3
/rev
990715-000
Shim Kit, End Cover Bearing
Models 33, 39, 46 / 54,4 – 63,7 – 75,4 cm
3
/rev
Item Part No. Qty. Description
41 A 103798-003 1 Bearing Shim
41 A 103798-005 1 Bearing Shim
41 A 103798-010 1 Bearing Shim
41 A 103798-015 1 Bearing Shim
41 A 103798-020 1 Bearing Shim
41 A 103798-030 1 Bearing Shim
Item Part No. Qty. Description
48 C 9900713-000 1 LPRV Plug S/A
Includes Below:
48-1 109077-00 1 LPRV Plug
48-2 8785-012 1 O-Ring
48-3 108870-002 1 LPRV Spring
48-4 108869-000 1 LPRV Poppet
48-5 16048-253* 10 Shim (.020)
LPRV = Low Pressure Relief Valve * See table for the Required Shims to Acheive PSI setting
etamixorppA
ISPmihS020.
023–003smihS5=
043–023smihS6=
843–043smihS7=
534smihS21=
Item Part No. Qty. Description
116 C 108395-000 1 Drive Shaft Seal
117 C 101680-250 1 Retaining Ring
118 C 107836-000 1 Spacer
Item Part No. Qty. Description
41 A 107744-003 1 Bearing Shim
41 A 107744-005 1 Bearing Shim
41 A 107744-010 1 Bearing Shim
41 A 107744-015 1 Bearing Shim
41 A 107744-020 1 Bearing Shim
41 A 107744-030 1 Bearing Shim
Item Part No. Qty. Description
12-6 95912-100 4 Cap Screw 5/16-18
12-7 108377-000 4 Washer
12-8 107858-000 4 Hold Down Strap
12-9 103237-001 4 Spacer
