48
T
roubleshooting
– Series 2 Variable Displacement Pump
Inspect External
Pump Control
Linkage (if Used)
1
Repair
or
Replace
Replace
Pump
Repair
or
Replace
Inspect
Charge
Check Valves
6
Repair
or
Replace
Inspect
System Relief
Valves
4
Repair
or
Replace
Repair
or
Replace
Inspect
Shuttle
Valve
5
Ok
OK
Defective
Defective
Ok
Ok
Ok
Defective
Defective
Defective
Inspect
Pump Control
Valve
2
Transmission Operates in One Direction Only
45
47
Table of Contents
Table of Contents
2
Introduction
3
Required Tools for Disassembly/Reassembly
3
Parts List
8
Main Housing
11
Servo Piston Sub-Assembly
11
Swash Bearing Sub-Assembly
11
Propel Valve Plate or V-Groove Plate
12
Bearing Plate
12
Drive Shaft Sub-Assembly
12
Rotating/Swash Plate Assembly
13
Charge Pump Kit Assemblies
14
End Covers
16
Control Valves
17
Manual Control Valve (Kit)
17
Manual Control Valve Wide Band (Kit)
17
Manual Control Valve with N/C Neutral Lockout & Potentiometer (Kit)
18
Manual Control Valve with N/C Neutral Lockout (Kit)
19
Manual Control Valve with Potentiometer (Kit)
20
(EP) Electronic Proportional Displacement Control (Kit)
22
Low Pressure Relief Valve Kit
25
Shim Kit, End Cover Bearing
25
Hold down (Kits)
35
Troubleshooting
41
Gauge Requirements, Gauge Port Size and Location
43
Pressure Readings
44
Fault-Logic Troubleshooting
45
Special Tools
53
