Eaton 26 Series User Manual

4
Series 26 - Model 26000 Multiple Gear Pump
Parts
Drawing
Shown below
Righthand (CW) Rotation
Triple Pump
8
Backup Gasket
9
Wear Plate
10
Seal
14
O-ring
57
Plug
10
Seal
10
Seal
9
Wear Plate
9
Wear Plate
8
Backup Gasket
8
Backup
Gasket
14
O-ring
14
O-ring
48
Adapter-Rear
15
Adapter-Front
7
Idler Gear
Assembly-Rear
29
Idler Gear
Assembly-Center
6
Idler Gear
Assembly-Front
14
O-ring
14
O-ring
14
O-ring
28
Body
3
Body
4
Body
Rear
45
Key
49
Gear-Center
26
Key
44
Gear-Rear
5
Drive Gear
Assembly
1
Front Plate
50
Washer
13
Cap Screws
11
Shaft seal
12
Washer
2
Backplate
25
Key
53
Plug
53A
O-ring
54
(Optional)
First Pump
Second Pump
Third Pump
Parts not
included in
double pump
