Model 72400
Parts List
Item Qty. Description
21Jam Nut
+3 1 Retaining Ring
+4 2 Retaining Ring
+6 1 Seal Washer
78Cap Screw, #10-24, 25,4mm [1.0 in.] Long
81Rotating Kit Assenbly
91Servo Piston Assembly
10 1 Servo Piston Follower
11 1 Cover Plate
+122Cover Plate Gasket
+141Housing Gasket
+161Control Housing Gasket
17 1 Cover Plate
18 1 Swashplate
19 2 Thrust Race
20 1 Thrust Bearing
21 1 Relief Valve for Port "A"
+ 21-1 1 O-ring, 2,95 mm Dia. x 23,47 mm I.D. [.116 in. Dia. x .924 in. I.D.]
22 1 Relief Valve for Port "B"
+ 22-1 1 O-ring, 2,95 mm Dia. x 23,47 mm I.D. [.116 in. Dia. x .924 in. I.D.]
23 4 Cap Screw, 3/8-16, 57,2 mm [2.25 in.] Long
24 2 Cap Screw, 3/8-16, 88,9 mm [3.5 in.] Long
25 2 Cap Screw, 3/8-16, 101,6 mm [4.0 in.] Long
26 6 Cap Screw
27 1 Valve Plate
28 1 Housing Assembly
28-1 1 Housing
28-2 Bearing (press fit)
28-3 1 Plug Sub-Assembly
+ 28-3-1 1 O-ring, 1,63 mm Dia. x 6,1 mm I.D. [.064 in. Dia. x .239 in. I.D.]
28-4 1 Cradle Sub-Assembly
28-4-1 2 Dowel Pin
28-4-2 1 Bushing
28-4-3 2 Cap Screw, Button Head
28-5 2 Cap Screw
28-6 2 Seal Sub-Assembly
29 1 endcover Assembly
29-1 1 Bearing (press fit)
29-2 1 Roll Pin
30 1 Key
31 1 Drive Shaft
+321O-ring,1,59 mm Dia. x 82,55 mm I.D. [.0625 in. Dia. x 3.25 in. I.D.]
+331Molded O-ring
34 1 Nut
35 2 Cap Screw, 3/8-16, 25,4 mm [1.0 in.] Long
36 1 Lockwasher
37 1 Washer
38 1 Plug
+ 38-1 1 O-ring, 2,21 mm Dia. x 16,36 mm I.D. [.087 in. Dia. x .644 in. I.D.]
