Electric Fire Pump Controllers & Transfer Switches
Part Number / Options Selection Guide
FD / FT & FDF / FTF (Foam) - Electric Fire Pump Controllers
For more information visit: www.chfire.com
PA05805031K
Electric Fire Pump Controllers & Transfer Switches
March 2014
N. Y. C.
APPROVED
U.B.C and C.B.C
Must Be Installed Per Applicable Code
and Manufacturers Recommendations
SEISMIC QUALIFIED
Part Number / Options Selection Guide
LMR
PLUS
PLUS
FT / FTF
FD / FDF = Stand Alone Controller
FT / FTF = Controller c/w Transfer Switch
A
-
Built-in Alarm System
B
-
Alarm Bell
20 = Limited Service
C1
-
Extra Contacts "Pump Run" (Two Form-C)
30 = Across the Line
C2
-
Extra Contacts "AC Power Failure" (Two Form-C)
40 = Part Winding
C3
-
Extra Contacts "Phase Rev." (Two Form-C)
50 = Primary Resistor C4
-
Remote Contacts (2 Form C) Low Reservoir
60 = Autotransformer
C5
-
Remote Contacts (2 Form C) High Reservoir
70 = Wye Delta (Star-Delta) Open
COM
-
Communications Option
80 = Wye Delta (Star-Delta) Closed
CX
-
Extra Contacts (Two Form-C; Specify Function)
90 = Soft Start
E1
-
NEMA 3R - Raintight Enclosure
E2
-
NEMA 4 - Watertight Enclosure
E3
-
NEMA 12 - Industrial Dust Tight Enclosure
E5
-
NEMA 4X - 304 Stainless Steel Enclosure
E8
-
Tropicalization
5 20 50 300 500
E9
-
NEMA 4X - Painted Steel
7.5 25 60 350 550
E10
-
NEMA 4X - 316 Stainless Steel Enclosure
10 30 75 400 600
EX
-
Export Crating
15 40 100 450 650
F2
- Floor Stand - 2 Inch Height**
H
-
High Withstand Rating (refer to tables)
I
-
Intermediate Withstand Rating (refer to tables)
LX
-
Extra Light (Specify Description)
P5
-
Proof Pressure Switch - ALCO 15-290 PSI
P7
-
Low Suction Pressure Switch
P8
-
Low Suction Shutdown (Requires P7)
A = 208V - 60HZ
P10
-
Pressure Transducer - Sea Water Rated
B = 240V - 60HZ L1 = English
P13
-
Externally Mounted Pressure Transducer**
C = 380V - 50HZ L2 = French
R1
-
Space Heater (120 / 220V)
D = 480V - 60HZ L4 = Italian
R2
-
Space Heater c/w Thermostat
E = 600V - 60HZ L5 = Spanish
R3
-
Space Heater c/w Humidistat
F = 415V - 50HZ L6 = Portuguese
R4
-
Low Pump Room Temperature Switch
H = 380V - 60HZ L7 = Chinese
R5
-
Space Heater (Externally powered - 120V)
J = 400V - 50HZ L8 = Polish
USB
-
Externally Mounted USB Port
K = 400V - 60HZ L9 = Dutch
X1
-
Printer
G2 = L11 = Turkish X2 - 4 Inch Chart Recorder ( 10 - 300 psi fresh water)
** Not available for NEMA 4 or NEMA 4X units.
* Only available on Limited Service Controllers
240V 60 HZ
Single Phase*
Language
Starting Type
Model
Options
* Higher Horsepowers not available on all
models. Consult Factory for pricing.
Voltage
125
250
200
150
700
Horsepower
