Eaton PKZM0-32/XTPR032BC1 User Manual

37
01/11 MN03402003Z-DE/EN
3 Installation
Installation Instructions
Fitting the device
Figure 6: Mounting the PKZM0/XTPR…BC1
h
The mechanical and electrical instructional leaflet
IL03407011Z (previous description AWA1210-1925) on
the inside of the cardboard package must be observed.
Danger!
Resets may be carried out at the installation or by trained
personnel in the control room.
a
a
a
a
b
b
b
f 15 mm
(0.59
" )
f 55 mm
(2.17
" )
