Eaton PKZM0-32/XTPR032BC1 User Manual

41
01/11 MN03402003Z-DE/EN
Anhang/Appendix
Typenschild/Rating plate
PKZM0/XTPR…BC1
Abbildung/Figure 9: Typenschild/Rating plate
PKZM0/XTPR…BC1
Die Zuordnungen der Werte zu den jeweiligen Typen sind der
nachfolgenden Tabelle 4 und Tabelle 5 zu entnehmen.
The assignment of the values to the individual types can be
found in the following Table 4 and Table 5.
165628
0102
SEE DIAL FOR
MOTOR FULL-
LOAD AMPS
BREAK ALL LINES
TRIP RATING
125 % OF
DIAL SETTING
MAX
HP
3 PH
1 PH
340B
115 200 230 460 575
V
MAX. RMS SYM AMPS MAX. FUSE MAX. C. B.
–
a
HP
b
c
d
–
f
HP
g
–
e
kA – 600 V AC
ABA C
A
WHEN PROTECTED BY ANY OF THE FOLLOWING:
SUITABLE FOR INSTALLATION
–LISTED CURRENT LIMITING CIRCUIT BREAKER PER UL 489
–LISTED FUSE
RATED AS SHOWN IN TABLE AND HAVING
AN INTERRUPTING RATING NOT LESS THAN
INDICATED
FOR FIELD WIRING SEE
INSTALLATION INSTRUCTION
MAN.MTR.
CNTLR
WARNING
THE OPENING OF THE BRANCH-CIRCUIT PROTECTIVE DEVICE
MAY BE AN INDICATION THAT A FAULT CURRENT HAS BEEN
INTERRUPTED. TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, CURRENT-CARRYING PARTS AND OTHER COMPONENTS
OF THE CONTROLLER SHOULD BE EXAMINED AND REPLACED
IF DAMAGED: IF BURNOUT OF THE CURRENT ELEMENT OF
AN OVERLOAD RELAY OCCURS, THE COMPLETE DEVICE MUST
BE REPLACED.
II(2)GD
PTB 10 ATEX 3013
Made in Germany Eaton Industries GmbH 53105 Bonn
GB 14048.2
50Hz
A002001
U
imp
= 6000 V
IEC/EN 60947-4-1
IEC/EN 60947-2
Category A
