Eaton PKZM0/XTPR BC1 Series User Manual

Description of device
29
01/11 MN03402003Z-DE/EN
Current ranges of the PKZM0/XTPR…BC1 motor-
protective circuit-breakers
The rated motor current is set on the PKZM0/XTPR…BC1
units by means of a current dial a (a fig. 1, page 28).
15 different types are available for monitoring motors with a
rated current from 0.1 to 32 A (a table 1).
Table 1: Current ranges of the PKZM0/XTPR…BC1
Part no.
Current range I
e
[A]
PKZM0-0,16 XTPRP16BC1 0.1 - 0.16
PKZM0-0.25 XTPRP25BC1 0.16 - 0.25
PKZM0-0.4 XTPRP40BC1
0.25 - 0.4
PKZM0-0.63 XTPRP63BC1 0.4 - 0.63
PKZM0-1 XTPR001BC1 0.63 - 1.0
PKZM0-1.6 XTPR1P6BC1 1.0 - 1.6
PKZM0-2.5 XTPR2P5BC1 1.6 - 2.5
PKZM0-4 XTPR004BC1 2.5 - 4
PKZM0-6.3 XTPR6P3BC1 4 - 6.3
PKZM0-10 XTPR010BC1 6.3 - 10
PKZM0-12 XTPR012BC1 8 - 12
PKZM0-16 XTPR016BC1 10 - 16
PKZM0-20 XTPR020BC1 16 - 20
PKZM0-25 XTPR025BC1 20 - 25
PKZM0-32 XTPR032BC1 26 - 32 open
26 - 30 enclosed
