MTL RTK P825 range of alarm annunciators
1 ANNUNCIATOR MODEL CODE DEFINITION
Code Description
Model No
SMA SmartAlarm
Alarm Ways
08
08 Way
16
16 Way
24
24 Way
32
32 Way
Individual Channel Repeat Relays
X
No Individual Channel Repeat Relays Fitted
R
Individual Channel Repeat Relay Fitted
Primary Supply – Internal PSU-1
A
Universal Input 85-264VAC & 88-300VDC
OR as an option which must be specied at time of order
D
19-72VDC (Must Be Specied At Time Of Order)
Aux Supply – Internal PSU-2 (Future)
X
Not Fitted
A
Universal Input 85-264VAC or 88-300VDC
OR as an option which must be specied at time of order
D
19-72VDC (Must Be Specied At Time Of Order)
Field Contact (Signal Supply) Internal / External
A
Internally Generated 24VDC / Ext Supplied 24VDC & 125VAC/DC
B
Internally Generated 24VDC / Ext Supplied 48VDC & 250VACVDC
LED Colour
R
Red
Y
Yellow
G
Green
B
Blue
W
White
I
Intermixed
Communications
X
Not Fitted
S
RS485 Serial Communications Fitted
Tropicalisation
X
Not Fitted
C
Tropicalised
IP Rating
4
IP40 Rated
5
Optional IP54
Special Options
X
Not Fitted
