Chengdu Ebyte Electronic Technology Co., Ltd. E90-DTU(400SL30P)User manual
Copyright ©2012–2019, Chengdu Ebyte Electronic Technology Co., Ltd
22
Three main configuration function descriptions
No.
Name
Description
1
Local configuration
See Figure 1 below to configure the radio's own operating parameters
2
Remote configuration
See Figure 2 below. It is used to remotely configure or read the parameters of
other radio stations or E22 modules. The configured radio stations or modules
are required to be in transparent transmission mode and enabled by wireless
configuration. Consistent with own station. Immediately after configuration
3
RSSI real-time
monitoring
Note: During remote configuration, if the airspeed is set to 0.3K, the reading
and writing speed will be slightly slower, please be patient
