Chengdu Ebyte Electronic Technology Co.,Ltd. E95-DTU(900SLxx-485) User Manual
Copyright ©2012–2022，Chengdu Ebyte Electronic Technology Co.,Ltd.
4.4 listen address
Example: Set the address of radio A to 0xFFFF and the channel to 0x04.
When radio station A is used as the receiver, it can receive all the data under the 0x04 channel to achieve the
purpose of monitoring.
5.Operating mode
E95-DTU has four working modes. When there is no strict low power consumption requirement, and normal
communication is required, it is recommended to configure the radio in the transparent transmission mode (mode
0);The default setting of the radio is transparent transmission mode (mode 0).
Serial port open, wireless open, transparent
transmission (factory default mode), support special
command air configuration.
Can be defined as WOR sender and WOR receiver,
support air wake-up
The user accesses the register through the serial port to
control the working state of the radio, and the user can
configure the radio through the host computer
configuration software.
Note: If there is no need for low power consumption, no need to care about the WOR mode (mode 1).
5.1 Transparent transmission mode (mode 0)
When the M0 indicator is off, the M1 indicator is off, and the radio works in mode 0
Users can input data through the serial port, and the radio will start wireless transmission.
The radio wireless receiving function is turned on, and the wireless data will be output
through the serial port TXD pin after receiving the wireless data.
