Echo CS-3000 TYPE 1E - SERIAL NUMBER 630330-665925 User Manual

4
Model
CS-3000 TYPE 1-E
CS-3400 TYPE 1-E
CS-3450 TYPE 1-E
Dimension
L x W x H
mm
260 x 230 x 220
380 x 230 x 245
inch
10.2 x 9.1 x 8.7
15.0 x 9.1 x 9.6
Weight
Power head, dry
kg
3.2 (7.1 lb)
3.3 (7.3 lb)
3.4 (7.5 lb)
Without chain and guide bar
Engine
Type
cc
Air-cooled, two-stroke, single cylinder
Displacement
30.1 (1.83 cu.in.)
33.4 (2.03 cu.in.)
Carburetor
Magneto
Spark Plug
Starter
Power transmission
Diaphragm type
Flywheel magneto : CDI system
NGK BPM-7A
Recoil starter
Automatic centrifugal clutch
Fuel
Mixture ratio
50:1 ratio with ECHO brand two-stroke oil.
89 octane unleaded. Do not use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE.
Tank Capacity
liter
0.25 (8.6 fl oz U.S.)
Oil
Bar and chain
ECHO bar and chain oil (or motor oil)
Tank Capacity
liter
0.15 (5 fl. oz. U.S.)
Guide bar
Saw chain
12 in. Standard
14 in. Standard
16 in. Standard
14, 16 in. Optional
12, 16 in. Optional
12, 14 in. Optional
Lubrication
Adjustable automatic oil pump
Standard
features
Top Handle
Conventional handle
Rear hand guard
Front hand guard,
Anti-vibration device,
Throttle control lockout, Chain brake,
Chain catcher, Spark arrestor muffler
TECHNICAL DATA
* Technical data subject to change without notice.

Echo CS-3000 TYPE 1E - SERIAL NUMBER 630330-665925 Specifications

General

Displacement	30.1 cc
Engine Type	2-stroke
Chain Pitch	3/8 inch
Chain Gauge	0.050 inch
Oil Capacity	0.2 liters
Recommended Bar Length	14 inches
Fuel Capacity	370 ml
