Echo EG-3500 User Manual

12
Read this operator’s manual and safety
rules before operating your generator.
3
5
6
8
9
10
11
12
13
1
2
1. Fuel Tank
2. Fuel Tank Cap
3. Fuel Level Gauge
4. Frame
5. 120V 3 Prong Twistlock
6. Ground (earth) Terminal
7. Low Oil Indicator
8. Oil Filler Cap
9. Ignition Switch
10. Recoil Starter
11. Fuel Valve
12. Air Filter Cover
13. Choke Lever
14. Spark Plug
15. Fuel Drain
16. Tap Extension Fuel Filter
7
4
GENERATOR COMPONENTS
10. DC Connection
11. DC Breaker
12. Hourmeter
13. 120V 3 Prong Twistlock
14. Ground
15. 120V GFCI
16. AC Breaker

Echo EG-3500 Specifications

General

Brand	Echo
Model	EG-3500
Category	Portable Generator
Language	English
