13
SRM-22GES
ADJUSTING NYLON LINE
• Make sure there is no bystander within 15 m radius and
pay enough attention to objects in the surroundings
before starting operation.
• Do not rotate the cutting head at more than 10,000
r/mim.
• Do not hit the cutting head against hard foreign matters
such as rocks, concrete, tree stub and bottle etc.
• When releasing Nylon line from spool hit tap knob of
spool against the ground surface lightly at rotation speed
lower than 4,500 r/min.
• Cut off knife on the shield adjusts cutting swath to 40 cm
automatically by cutting nylon lines evenly when
attachment starts rotating.
• When operating with less than maximum cutting swath
(40 cm), cut two nylon lines in equal lengths.
Tap knob
Nylon line comes out
Hit knob against the
ground surface lightly
NYLON LINE HEAD
Type : G138
Thread : Left-hand thread M 10 × 1.25 pitch
CAUTION
Use only flexible, non-metallic line recommended
by KIORITZ CORPORATION.
G138
To Next Page
