20
PRE - OPERATION
OPERATION
WITH BLADES
Preparing the Trimmer/Brush Cutter for Blade Use
WARNING DANGER
Blade use DEMANDS specific Brush Cutter configuration. Operation without specified shield and harness can result
in serious personal injury.
Plastic and Nylon Blades Require "Blade Conversion Kit," P/N 99944200415
(TRI-CUT [A] and shoulder harness [B]).
or U-Handle/Blade Conversion Kit P/N 99944200451
MUFFLER BRACKET INSTALLATION
Tools Required: 4mm Hex Wrench
Parts Required: Muffler Bracket Kit P/N 10099057730
IMPORTANT
Use of the Brush Cutter on U.S. Forest land and the states of
California, Oregon and Washington requires installation of
optional Muffler Bracket Kit P/N 10099057730.
1. Remove upper and lower bolts from right side of starter housing.
2. Position muffler bracket (A) over bolt holes so it extends over
muffler cover.
3. Secure bracket using two (2) 4x16 socket head bolts (B) supplied
with bracket kit.
B
A
