Ecolab Chameleon SP Series User Manual

10
7. Recommended spare parts
Satellite
Nr. Description Amount
0664136 Non-return valve, air
1
0646050 Non-return valve, detergent
1
0603338 Non-return valve, water
1
8. Specifi cations
The most important specifi cations are shown on the serial plates on the main station/satellite and pump, respec-
tively.
Adv.
Water Unit Pneumatic SP Automatic SA
Max. outlet pressure. bar 40 40
Comsumption during rinsing. L/min 30 30
Comsumption during foaming. L/min 10 10
Min. supply prssure. bar 12 12
Max. supply pressure. bar 40 40
Min. water supply. L/min 30 30
Max. water temp. °C 70 70
Pipe dimension inlet Ø inch 1/2” 1/2”
Pipe dimension outlet Ø inch 1/2” 1/2”
Compressed air
Min/Max air pressure bar 5-10 5-10
Compressed air consumption NL/min 200 200
Pipe dimension inlet Ø mm 6 6
General
Dimensions mm 330 x 403 x 215 330 x 403 x 215 330 x 403 x 215
Weight kg 15 15 15
Electricity
Supply voltage V 1N/PE 110/230 V
85-0%...265+0%
24 V DC ± 10%
Frequency Hz 50/60 Hz
48-0%...62+0%
Power W 3
