ECS 945P-A User Manual

11
Installing the Motherboard
CPUFAN1: CPU Cooling FAN Power Connector
SYSFAN2/3: System Cooling FAN Power Connectors
Pin Signal Name Function
1 GND System Ground
2 +12V Power +12V
3 Sense Sensor
ATX1: ATX 24-pin Power Connector
Pin Signal Name Pin Signal Name
1 +3.3V 13 +3.3V
2 +3.3V 14 -12V
3 Ground 15 COM
4 +5V 16 PS_ON
5 Ground 17 COM
6 +5V 18 COM
7 Ground 19 COM
8 PWRGD 20 -5V
9 +5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 COM
Pin Signal Name Function
1 GND System Ground
2 +12V Power +12V
3 Sense Sensor
4 PWM CPU FAN control
Users please note that the fan connector supports the CPU cooling
fan of 1.1A~2.2A (26.4W max.) at +12V.
ATX12V1: ATX 12V Power Connector
Pin Signal Name
4 +12V
3 +12V
2 Ground
1 Ground
ATX4P1: Auxliary Power Connector for Graphics Interface
Pin Signal Name
4 +12V
3 GND
2 GND
1 NC
Make sure to connect a 4-pin ATX power cable
to ATX4P1; otherwise, the system will be un-
stable.
