ECS AMD690GM-M2 User Manual

5
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
Socket AM2 for AMD Athlon
™
64 X2 Dual-Core/
Althlon
™
64/Sempron
™
processors
2.DIMM1~2
240-pin DDR2 SDRAM slots
3.ATX_POWER
Standard 24-pin ATX power connector
4.FDD
Floppy disk drive connector
5.IDE1
Primary IDE connector
6.WOL1*
Wake On LAN Connector
7.SATA1~4
Serial ATA connectors
8.JLPC1
TPM header
9.IRDA*
Infrared header
10.CLR_CMOS
Clear CMOS jumper
11.PANEL1
Front panel switch/LED header
12.USB3~5
Front Panel USB headers
13.COM1
Onboard serial port header
14.CD_IN1
Analog audio input connector
15.AUDIO1
Front panel audio header
16.SPDIFO
SPDIF out header
17.PCI1~2
32-bit add-on card slots
18.PCIEX16
PCI Express x16 slot for graphics interface
19.PCIEX1
PCI Express x1slot
20.TV_OUT1
TV-out header
21.SYS_FAN
System cooling fan connector
22.ATX12V
Auxiliary 4-pin power connector
23.CPU_FAN
CPU cooling fan connecto
r
1.CPU Socket
* Stands for optional components
