PC Health Status

On motherboards support hardware monitoring, this item lets you monitor the

parameters for critical voltages, temperatures and fan speeds.

Scroll to this item and press <Enter> to view the following screen:

Smart Fan Function

CPU/System Fan Smart Fan Control (Enabled)

These items enable you to define the CPU/system fan by smartly adjusting the CPU/

system fan. When it is set at certain temperature, the CPU/system fan PWM value

will change accordingly.

Main Advanced Chipset M.I.B. III Boot Security Exit

+/- : Change Opt.

Enter/Dbl Click : Select





: Select Screen

/Click: Select Item

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC/Right Click: Exit

CPU Temperature (DTS) : 50

CPU Fan Speed : 1541 RPM

System Fan Speed : 0 RPM

CPU Voltage : 1.788V

DIMM Voltage : 1.512V

TCC Activation Temperature (DTS) 100

Smart Fan Function

PC Health Status

Enable CPU SmartFan

Main Advanced Chipset M.I.B. III Boot Security Exit

CPU Smart Fan Control Enabled

Smart Fan Mode Normal

Smart Fan start PWM value 180

Smart Fan start PWM TEMP(DTS) 70

DeltaT +3

Smart Fan Slope PWM value 10 PWM value/unite

CPU Fan Full Speed Offset (DTS) 77

System Fan Smart Fan Control Enabled
