PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
paremeters for critical voltages, temperatures and fan speeds.
Smart Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be
auto adjusted depending on the CPU temperature. If you choose Quite mode, the
fan speed will be auto minimized for quiet environment. If you choose Silent mode,
the fan speed will be auto restricted to make system more quietly. If you choose
Manual mode, the fan speed will be adjust depending on users’ parameters.
Version 2.02.1205. Copyright (C) 2012, American Megatrends, Inc.
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function
+/- :Change Opt.
Enter : Select
F1:General Help
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
Main
Advanced Chipset M.I.B X Boot Security Exit
SoC Temperature 32°C
System Temperature 32°C
CPU Fan Speed 0 RPM
System Fan Speed 0 RPM
CPU Voltage 0.814V
DIMM Voltage 1.364V
+12V 12.474V
+5V 5.027V
+3.3V 3.520V
Smart Fan Function
PC Health Status
+/- :Change Opt.
Enter : Select
F1:General Help
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
Main Advanced Chipset M.I.B X Boot Security Exit
Smart Fan Select [CPU]
Smart Fan Mode [Normal]
Smart Fan start PWM value 180
Smart Fan start PWM TEMP (°C) 45
DeltaT 3
Smart Fan Slope PWM value 10
Fan Full Limit Temp (°C) 52
Smart Fan Select
Smart Fan Select (CPU)
This item allows you to change and configure Smart Fans on CPU Fan or System Fan.
Smart Fan start PWM value (180)
This item is used to set the start PWM value of the smart fan.
To Next Page
