H61H2-I5 USER MANUAL
28
Chapter 2
fCPU OverClocking Configuration
Scroll to this item to view the following screen:
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Enhanced Intel SpeedStep
Technology
Main Advanced Chipset M.I.B III Boot Security Exit
CPU OverClocking Configuration
CPU Frequency 100
CPU Ratio 31
Enhanced Intel SpeedStep Technology [Enabled]
Turbo Mode [Enabled]
Internal PLL OverVoltage [Disabled]
Runtime Turbo Enable [Disabled]
Over Clocking Extra Vol.(1/256 V) 0
IA Core Current Maximum
iGFX Core Current Maximum
Long Duration Power Limit Override Maximum
Long Duration Power Maintianed 10
Short Duration Power Limit Override Maximum
1 Core Ratio Limit 34
2 Core Ratio Limit 33
3 Core Ratio Limit 33
4 Core Ratio Limit 32
Intel Graphics Configuration
Graphics Core Ratio Limit 22
Graphics Voltage(1/256) 0
F2:Previous Values
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B III (MB Intelligent BIOS III) Menu
M.I.B III (MB Intelligent BIOS III)
CPU OverClocking Configuration
Chipset OverClocking Configuration
B.O.M.P Technology [Enabled]
Auto Detect DIMM/PCI Clk [Enabled]
Spread Spectrum [Enabled]
Intel(R) Core (TM) i5-2400 CPU @ 3.10GHz
Processor Speed 3100 MHz
Memory Frequency 1333 MHz
Total Memory 2048MB (DDR3 )
Main Advanced Chipset M.I.B III Boot Security Exit
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
CPU OverClocking Configuration
f
f
F2:Previous Values
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
To Next Page
