H61H2-I5 USER MANUAL
32
Chapter 2
Boot Menu
This page enables you to set the boot device priority.
Boot Configuration
This item shows the information of the boot configuration.
Bootup NumLock State (On)
This item determines if the NumLock key is active or inactive at system start-up
time.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1229. Copyright (C) 2012, American Megatrends, Inc.
Boot Configuration
Operation System Select [Windows 7 or other OS]
Launch PXE OpROM [Disabled]
Launch Storage OpROM [Enabled]
Fast Boot [Disabled]
Bootup NumLock State [On]
Quiet Boot [Enabled]
Boot mode select [LEGACY]
Set Boot Priority
Boot Option #1 [Hard Disk]
Boot Option #2 [CD/DVD]
Boot Option #3 [USB/Floppy]
Boot Option #4 [USB CD/DVD]
Boot Option #5 [USB Hard Disk]
Boot Option #6 [USB Flash:JetFlashTS4GJFV20 0.00]
Boot Option #7 [Network]
USB Flash Drive Priorities
Boot Option #1/#2/#3/#4/#5/#6/#7/ (Hard Disk / CD/DVD / USB/Floppy / USB CD/DVD
/ USB HardDisk / USB Flash / Network)
These items show the boot priorities.
Main Advanced Chipset M.I.B III Boot Security Exit
F2:Previous Values
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Launch PXE OpROM (Disabled)
Use this item to enable or disable the PXE OpROM.
Launch Storage OpROM (Enabled)
Use this item to enable or disable the Storage OpROM.
Quiet Boot (Enabled)
This item determines if the NumLock key is active or inactive at system start-up
time.
Boot mode select (LEGACY)
Use this item to select boot mode.
Windows 7 or other OS: Boot
policy for Legacy OS
Windows 8: Boot Policy for UEFI
OS without Compatibility Support
Module (CSM)
Manual: User customized CSM
parameters & boot policy
Operation System Select (Windows7 or other OS)
This item is used to select the operation system.
Fast Boot (Disabled)
Use this item to enable or disable the fast boot.
f
To Next Page
