ECS H61H2-M12 User Manual

36
Using BIOS
SATA Configuration
Use this item to show the mode of serial ATA configuration options.
Serial-ATA Controller 0/1 (Compatible/Enhanced)
Use these items to select the Serial-ATA controller options: Disabled, Compatible,
Enabled.
SATA Port1~4 (Not Present)
This motherboard supports four SATA channels and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel,
and each channel allows one SATA device to be installed. Use these items to configure
each device on the SATA channel.
SATA Mode (IDE Mode)
Use this item to select SATA mode.
Execute Disable Bit (Enabled)
This item allows the processor to classify areas in memory by where application
codecan execute and where it cannot. When a malicious worm attempts to insert
code inthe buffer, the processor disables code execution, preventing damage or worm
propa-gation. Replacing older computers with Execute Disable Bit enabled systems
can haltworm attacks, reducing the need for virus related repair.
Intel Virtualization Technology (Enabled)
When disabled, a VMM cannot utilize the additional hardware capabilities providedby
Vandor Pool Technology.
Enhanced Halt (C1E) (Enabled)
This item enables or disables enhanced halt.
Press <Esc> to return to the Advanced Menu page.
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
SATA Configuration
SATA Mode IDE Mode
Serial-ATA Controller 0 Compatible
Serial-ATA Controller 1 Enhanced
SATA Port1 Not Present
SATA Port2 Not Present
SATA Port3 Not Present
SATA Port4 Not Present
(1) IDE Mode. (2) AHCI
Mode.
