ECS H61H2-M12 User Manual

53
Using BIOS
This page enables you to set the keyboard NumLock state.
Boot Menu
Bootup NumLock State (On)
This item enables you to select NumLock state.
1st/2nd/3rd/4th/5th/6th/7ht/8th Boot
These items set the system boot order.
Hard Diks Drive BBS Priorities
This item enables you to specify the sequence of loading the operating system from
the installing hard disk drives.
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
Select the keyboard
NumLock state
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Boot Configuration
Bootup NumLock State On
Set Boot Priority
1st Boot Hard Disk
2nd Boot CD/DVD
3rd Boot USB Floppy/Floppy
4th Boot USB CD/DVD
5th Boot USB Hard Disk
6th Boot USB KEY
7th Boot Network
8th Boot UEFI
CD/DVD ROM Drive BBS Priorities
Hard Disk Drive BBS Priorities
USB Floppy/Floppy Drive BBS Priorities
USB CD/DVD ROM Drive BBS Priorities
USB HardDisk Drive BBS Priorities
USB KEY Drive BBS Priorities
NETWORK Device BBS Priorities
UEFI Boot Drive BBS Priorities
CD/DVD ROM Drive BBS Priorities
This item enables you to specify the sequence of loading the operating system from
the installing CD/DVD ROM drives.
USB Floppy/Floppy Drive BBS Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB floppy/floppy drives.
USB Hard Disk Drive BBS Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB hard disk drives.
USB KEY Drive BBS Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB KEY drives.
USB CD/DVD ROM Drive BBS Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB CD/DVD ROM drives.

ECS H61H2-M12 Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
CPU fan connector	Yes
Number of SATA II connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
On-board graphics card	-
Parallel processing technology support	Not supported
Networking features	Fast Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	170 mm
Width	225 mm
