Chapter 3
H77H2-M4 USER MANUAL
34
LAN Configuration
The item in the menu shows the LAN-related information that the BIOS
automatically detects.
Press <Esc> to return to the Advanced Menu page.
Enabled/Disabled Onboard
LAN 1 Controller
Main Advanced Chipset M.I.B III Boot Security Save & Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Onboard LAN Controller (Enabled)
Use this item to enable or disable Onboard LAN 1 controller.
LAN Configuration
Onboard LAN Controller Enabled
Network stack Enabled
Ipv4 PXE Support Enabled
Ipv6 PXE Support Enabled
Network stack (Enabled)
Use this item to enable or disable UEFI network stack.
Ipv4/6 PXE Support (Enabled)
Use these items to enable or disable the Ipv4/6 PXE Boot support. If disabled
IPV4/6 PXE boot option will not be created.
