Questions and Answers:

M
Melissa SantosAug 20, 2025
What to do if power is on, fans are running but there is no display on ECS Motherboard?
- B
  billysullivanAug 20, 2025
  If your ECS Motherboard's power is on and the fans are running, but there is no display, try the following: * Ensure the monitor is turned on and the monitor cable is properly connected to the PC. * Check that the VGA adapter card (if applicable) is inserted properly. * Listen for beep sounds. If you are using an internal PC speaker, make sure it is connected: * Continuous 3 short beeps: memory not detected. * 1 long beep and 8 short beeps: VGA not detected.
M
Melissa AyalaAug 27, 2025
Why does my ECS Motherboard PC suddenly shuts down while booting up?
- M
  Mr. Brandon SantosAug 27, 2025
  If your ECS Motherboard-based PC suddenly shuts down while booting up, it might be due to CPU overheating. Apply thermal grease onto the CPU heatsink and ensure the CPU fan is well-connected with the CPU heatsink. Also, check if the CPU fan is working properly while the system is running. You can also try disabling the Smartfan function in the BIOS settings to let the fan run at default speed by doing a Load Optimised Default.
T
Timothy SmithSep 3, 2025
What to do if PC may experience start up problems again after prolong use with ECS H77H2-M4 Motherboard?
- N
  Nicole MurraySep 3, 2025
  If your ECS Motherboard PC experiences start-up problems after prolonged use, consider the following: 1. Clear the CMOS values using the CLR_CMOS jumper. 2. Check the CPU cooler fan for dust. Clean the cooler or replace it if necessary. 3. Ensure that the 12V power & ATX connectors are fully inserted into the motherboard connectors. 4. Remove the hard drive, optical drive, or DDR memory to determine which component may be at fault. 5. Check whether there is any bulged electrolytic capacitor or abnormal component, which could indicate a breakdown of devices connected to the motherboard.

ECS H77H2-M4 Specifications

General

Form Factor	Micro ATX
Socket	LGA 1155
Chipset	Intel H77
Memory Type	DDR3
Max Memory Support	32GB
Memory Standard	DDR3 1600/1333/1066
PCI Express 3.0 x16	1
PCI Express 2.0 x1	1
PCI	1
SATA 6Gb/s	2
SATA 3Gb/s	4
USB 3.0 Ports (Rear)	2
USB 2.0 Ports (Rear)	4
USB 3.0 Ports	2
Ethernet	Realtek RTL8111E Gigabit LAN
USB 2.0 Ports	8
Video Output	HDMI, DVI, VGA
