H81H3-M3 USER MANUAL
55
Chapter 3
This page enables you to set the keyboard NumLock state.
Boot Menu
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
Windows 7 or other OS:
Boot policy for Legacy OS
Windows 8: Boot Policy for
UEFI OS without
Compatibility Support
Module (CSM)
Manual: User customized
CSM parameters & boot
policy
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Boot Configuration
This item shows the information of the Boot Configuration.
Bootup NumLock State (On)
This item enables you to select NumLock state.
Quiet Boot (Enabled)
This item enables or disables quiet boot.
Boot Mode Select (LEGACY)
Use this item to select boot mode.
Operating system select (Windows7 or other OS)
This item is used to select the operation system.
Boot Configuration
Launch PXE OpROM (Disabled)
The item enables or disables launch PXE Option ROM.
Launch Storage OpROM (Enabled)
The item enables or disables launch Storage Option ROM.
Set Boot Priority
This item enables you to set boot priority for all boot devices.
Boot Option #1/2/3/4/5/6/7
These items show the boot priorities.
Operating system select Windows7 or other OS
Launch PXE OpROM
Disabled
Launch Storage OpROM Enabled
Fast Boot Disabled
Bootup NumLock State On
Quiet Boot Enabled
Boot Mode Select LEGACY
Set Boot Priority
Boot Option #1 Hard Disk: ST3250620...
Boot Option #2 CD/DVD: HL-DT-ST BDD...
Boot Option #3 USB/Floppy
Boot Option #4 USB CD/DVD
Boot Option #5 USB Hard Disk
Boot Option #6 USB Flash: Ut165 1.00
Boot Option #7 Network
Fast Boot (Disabled)
This item enables or disables fast boot.
Hard Disk Drive Priorities
CD/DVD ROM Drive Priorities
USB Flash Drive Priorities
